Extrusion compound
本文
-
Application
- Sash window, bordering lining for office furniture, waterspout and other profile processed products.
Features
- Easy profile extrusion
- excellent usability
-
Major physical properties and process temperature
| Test Item | UNIT | Value | Test method | ||
|---|---|---|---|---|---|
| WS-17HS | RP-300 | ||||
| Room Temp. | Tensile Strength | Mpa | 15.1 | 51 | ASTM D 638 |
| Elongation | % | 346 | 75 | ||
| Bending Elastic Modules | kgf/㎠ | - | 23,201 | ASTM D 792 | |
| Specific Gravity | - | 1.27 | 1.56 | ASTM D 792 | |
| Hardness | Shore A | 62 | - | ASTM C 2240 | |
| Rockwell | - | 102 | ASTM D 786 | ||
| Thermal Stability (180℃) |
hrs | 3:35 | 3:40 | JIS K 6723 | |
| Application | Soft PVC for Window Pfofile |
Rigid PVC for Sash & Pfofile |
|||
- Product characteristics shown above are only guidelines not the actual product specification.
- Process temperature conditions for the product may differ according to the technical spec of the machinery and processing condition.
